KX057-5

COMPACT EXCAVATORS

Call for Pricing

The Kubota KX057-5 doesn’t just give you the best in durability, comfort and performance-- it embodies Kubota’s ever-growing pursuit of innovation. Rated at 47.6 horsepower, the compact excavator is built to help you dig deeper, lift higher and dominate whatever task you throw its way. Let’s get to work. Kubota is the world’s #1 selling compact excavator for 20 years.*

*According to 2023 data from Off-Highway Research including all Kubota Group brand sales.



Shop

Find Parts

Build

My Equipment

Download

Specifications

Compare

Specifications

Special Offers

  • Save on Select Kubota Construction Equipment

    Save on Select Kubota Construction Equipment

    0% For 60 months OR Save Up to $12,000*

    Expires 12/31/2026
  • EXCAVATORS

    EXCAVATORS

    0% A.P.R. for up to 60 months OR save up to $12,000 on K, KX, and U Series Excavators!

    Expires 1/1/2027
  • CONSTRUCTION

    CONSTRUCTION

    $0 Down, 0% A.P.R. for up to 60 Months or Save up to $12,000 on Construction Equipment!

    Expires 1/1/2027
    KX057-5

    KX057-5

    HP

    Call for Pricing

    Specifications

    Arm Breakout Force, lbs (kgf)

    5463 (2478)

    Auxiliary Hydraulics Flow Rate, GPM (LPM)

    19.8 (75) / 9.8 (37)

    Blade Height, in (mm)

    16.1in (410), Angle Blade: 25/25

    Blade Width, ft (mm)

    6ft 5.2in (1960)

    Bucket Breakout Force, lbs (kgf)

    10172 (4614)

    Crawler Length, ft (mm)

    8ft 2in (2500)

    Displacement (cu. in.)

    159.6

    Engine Model

    Kubota V2607-CR-E5

    Fuel Reservoir, gal (l)

    19.3 (73)

    Ground Contact Pressure psi, kgf (cm2)

    Rubber canopy/cab: 4.6 (0.32) / 4.7 (0.33), Angle blade rubber canopy/cab: 4.8 (0.33) / 4.9 (0.34), Angle blade steel canopy/cab: 4.9 (0.34) / 4.9 (0.34)

    Horsepower (gross)

    47.6

    Hydraulic Oil Reservoir / System, gal (l)

    11.1 (41.9) / 20.3 (77.0)

    Min. Ground Clearance, in (mm)

    12.2in (310)

    Operating Weight, lbs (kg)

    Rubber: 12200 (5535) / 12400 (5625), Angle blade rubber: 12346 (5600) / 12577 (5705) Angle blade steel: 13106 (5945) / 13338 (6050)

    Overall Height, ft (mm)

    8ft 4in (2550)

    Overall Length, ft (mm)

    18ft 1in (5520)

    Overall Width, ft (mm)

    6ft 5in (1960)

    Pump Capacity, GPM (LPM)

    14.8 (56.1) Variable x 2 / 9.8 (37.0) Gear x 1

    Traveling Speed: High, mph (kph)

    3.0 (4.8)

    Traveling Speed: Low, mph (kph)

    1.7 (2.8)
